ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use

اطلاعات پایه
محل منبع: چین
نام تجاری: SAFEGAS
گواهی: ATEX/EMC/IECEX
شماره مدل: حداقل
مقدار حداقل تعداد سفارش: 1
قیمت: قابل مذاکره
جزئیات بسته بندی: کارتن
زمان تحویل: 3 روز کاری
شرایط پرداخت: T/T، وسترن یونیون
قابلیت ارائه: 3000 عدد در ماه
اطلاعات تکمیلی
اصل تشخیص: انتشار ابعاد: 90mm*60mm*33mm (طول*عرض*ضخامت)
گاز شناسایی شده: CL2 دامنه اندازه گیری: 0-10ppm 0-50ppm
قطعنامه: 0.01ppm وزن (با گیره): 125 گرم
دقت: 2-5 ≤ 5 ٪ FS حالت زنگ: زنگ صدا، نور و لرزش
فشار هوای کاری: 86 تا 106 کیلوپاسکال زمان پاسخ (T90): 15 تا 30
کلاس حفاظت: IP66/68 دمای کاری: -20 ℃ تا 55
اصل: اصل الکتروشیمیایی صدور گواهینامه ضد انفجار: iecex ، atex
رطوبت کار (غیرقانونی): 0-95٪ RH نمایش: نام گاز، توان باتری، واحد غلظت، مقدار اندازه گیری شده
حالت منبع تغذیه:: باتری خشک 3.6 ولت (غیر قابل شارژ و قابل تعویض) نوع زنگ هشدار: آلارم کم، زنگ بالا، STEL، TWA، کالیبراسیون اختیاری باتری کم به دلیل و تست ضربه به دلیل

توضیحات محصول

ATEX Certified Portable Single Toxic Gas Detector For Chlorine Industrial Wastewater Plant Use
Product Overview

The MiniMeta Portable CL2 Gas Detector is a high-precision portable gas detector designed for chlorine detection using diffusion detection principle, specifically engineered for industrial safety applications in wastewater treatment plants and similar environments.

This IECEX/ATEX/EMC certified single-gas detector can detect hundreds of user-selected toxic gases. User-friendly and easy to operate, it features replaceable battery and sensor for long-term protection, offering a low-cost, long-term ownership gas monitoring system.

Key Features
  • IP68 water- and dust-resistant case
  • Low power consumption with 2 years standby time - no battery charging or calibration needed
  • Optional single/multi unit docking station for daily bump test and calibration
  • Event and data logging function
  • Self-test function for improved safety through automatic self-testing
  • Small size, lightweight design with back clip for easy carrying
  • 95db@30cm buzzer alarm, 2 high-bright red LED light alarm and vibration alarm
  • Real time value, TWA, STEL, MAX, MIN multiple numerical display
Applications
  • Sewage treatment plant chlorine leak inspection
  • Chemical chlorination workshop toxic gas monitoring
  • Swimming pool disinfection room gas concentration testing
  • Pesticide manufacturing workshop harmful gas early warning
  • Textile bleaching factory workplace safety detection
  • Municipal water disinfection station chlorine leakage alarm
  • And more industrial applications
Portable Chlorine Gas Detector front view showing display and controls Portable Chlorine Gas Detector side view showing compact design Portable Chlorine Gas Detector display close-up showing readings Portable Chlorine Gas Detector back view with carrying clip Portable Chlorine Gas Detector in use scenario at industrial site
Technical Parameters
Parameter Specification
Detect gas CL2 (Chlorine)
Sensor type Electrochemical
Sampling method Diffusion
Measure range 0-10ppm / 0-50ppm
Resolution 0.01ppm
Precision ≤± 3% F.S.
Response Time ≤30s (T90)
Display Gas name, concentration unit, measured value, battery level
Alarm mode Sound, light, vibration alarm
Alarm type Low alarm, high alarm, STEL, TWA, low battery
Operating language Chinese/English
Size 90×60×33mm
Weight 125g
Working Temperature -20ºC to 50ºC
Working Humidity 0-95%RH
Working air pressure 86-106kpa
Company Advantages
  • R&D team experience: over 25 years
  • Company certifications: ISO9001, ISO45001
  • Product certifications: IECEx, ATEX, CE
  • Delivery time: 5-7 days
  • Annual capacity: 80,000 units
  • Professional 7×24 hours customer service
Manufacturer Profile

Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) specializes in the design, production, and sales of gas detection equipment and systems. With 16 years of industry experience, we provide comprehensive solutions for various sectors including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronics, Municipal Engineering, Agriculture, and Household Appliances.

Product Line
Portable Detectors:
  • Minimeta, Micmeta, YT-1200H-S, SKY3000, SKY2000, SKY8000, SKY1000, MAXMETA
Fixed Systems:
  • YT-95H, YT-98H, YT-96H, SG100, SG200
Controllers:
  • YT-1100H, YT-1600H, YT-1800H
Particle Counters:
  • AQD5000, SKY6000-PM, SKY2000-PM
Gas detection product line overview showing various models Industrial gas detection systems installation Gas detection controller units and panels
